The CityRider is a high-performance mobility scooter designed for urban environments. Its advanced features and robust construction ensure reliable operation and precise control.
Key Features:
- All-round suspension system for enhanced stability
- Ergonomic captain's chair with adjustable tiller
- Comprehensive lighting system (front and rear)
- Rearview mirror for increased awareness
- Separate cable brake system
Technical Specifications:
Dimensions:
- Overall Length: 46.4" / 118 cm
- Overall Width: 23.2" / 59 cm
- Overall Height: 48.8" / 124 cm (at maximum and minimum tiller height)
- Turning Radius: 56.3" / 143 cm
Weight:
- With Batteries: 206.4 lbs / 93.8 kg
- Without Batteries: 154 lbs / 70 kg
Seating:
- Type: Captain seat
- Dimensions: 19" x 17" x 26" (Width x Depth x Height)
- Cushion Thickness: 2.5" - 3"
Performance:
- Battery: 35AH SLA
- Motor: 470W 5300RPM
- Maximum Speed: 6 MPH
- Driving Range: Up to 17 miles / 27.3 km
- Maximum Load Capacity: 350 lbs / 160 kg
- Maximum Recommended Climbing Angle: 8°
Additional Features:
- Tire Type: Flat-free solid
- Brake System: Electromagnetic
- Controller: PG70A
- Charger: 4A Off-Board (Charging Time > 8hr)
- Colors: Red, Black, Sunset Orange
SPECS
| Overall Length | 46.4″/ 118 cm |
| Overall Width | 23.2″ / 59 cm |
| Overall Height (at Maximum Tiller Height) | 48.8″ / 124 cm |
| Overall Height – at Minimum Tiller Height | 48.8″ / 124 cm |
| Legroom – Floorboard Length x Width | 12” x 19” |
| Deck Height – Floorboard to Floor | 5.5” |
| Ground Clearance | 2.5” / 75 mm |
| Turning Radius | 56.3″/143 cm |
| Folded Overall Length | NA |
| Folded Overall Width | NA |
| Folded Overall Height | NA |
| Weight with Std. | 206.4lbs/93.8kg |
| Weight with Batteries | 206.4lbs/93.8kg |
| Weight without Batteries | 154 lbs/70kg |
| Seat Type | Captain seat |
| Seat – Width & Depth & Height | 19 “ x 17 “ x 26” |
| Seat – Cushion Thickness | 2.5”~ 3” |
| Seat Height – Cushion to Deck | 18” |
| Seat Height – Cushion to Floor | 20.5” |
| Tire Type | Flat free – solid |
| Rim Type Rear | Aluminum |
| Rim Type Front | 4” |
| OEM Spec Rear | |
| Outside Diameter Rear | 300-4×2(10″) |
| Tire Width Rear | 3” |
| OEM Spec Front | |
| Outside Diameter Front | 300-4×2(10″) |
| Tire Width Front | 3” |
| Battery Type & Power | 35AH SLA Batteries |
| Brake System | Electromagnetic Brake |
| Climbing Angle – Maximum Recommended | 8° |
| Charger Type | 4A Off-Board |
| Charging Time | >8hr |
| Controller | PG70A |
| *Driving Range | Up to 17 miles / 27.3 km |
| Load Capacity | 350 lbs / 160 kg |
| Motor & Drive Location | 470W 5300RPM |
| *Speed – Maximum | 6 MPH |
| Colors | Red, Black, Sunset Orange |
| Tiller Type | DELTA |
| Throttle Control Type | Wigwag |
| Anti-Tipper Wheels-Rear | Yes |
Manual: CLICK HERE
Warranty: CLICK HERE
